Relationships

A relationship is an association between two models that describes how rows in one relate to rows in another. Relationships let NQRust Analytics join models and analyze connected data efficiently, and they provide the AI service with explicit join paths rather than requiring it to infer them.

Create a relationship

During the connection process

When you connect a data source, you can define relationships between the selected tables as an optional step.

From the Modeling page

The relationship dialog with From and To model/column pickers and the relationship Type selector.

Limitations

Two cases are not supported when creating relationships:

Self-referential relationships. A column in a model cannot point back to the same model. For example, an Employee model whose reportsTo column stores another Employee ID cannot be modeled directly. This means hierarchical or recursive structures within a single model are not supported.

Duplicate relationships. You cannot create two relationships between the same pair of models using identical columns. If an Order–Customer relationship already uses customerID, you cannot add another one on the same customerID. This keeps each relationship unique and avoids ambiguity.

Update a relationship

1. Click the ... icon next to the relationship on the model diagram.
2. Choose Edit.
3. Change the relationship Type.

Delete a relationship

1. Click the ... icon next to the relationship on the model diagram.
2. Choose Delete.

Inspect a relationship

Hover over the line connecting two model diagrams to see details about that relationship.

Deploy your changes

After editing on the Modeling page, click Deploy in the navbar to sync your changes to the Analytics Engine.
